| Parameter | |
|---|---|
| Central Wavelength (λc) | 1310nm, 1480nm, or 1550nm |
| Band Width | ± 40 nm |
| Insertion Loss | ≤ 0.6 dB (0.4 dB typ.) |
| Extinction Ratio | ≥ 20 dB (25 dB typ.) |
| Directivity | ≥ 50 dB |
| Return Loss | ≥ 45 dB |
| Fiber Type of Port 1 & 2 | PM Panda Fiber |
| Fiber Type of Port 3 | SMF 28e or PM Panda Fiber |
| Maximum Power | 300 mW |
| Fiber Tensile Load | 5 N |
| Operating Temperature | 0°C ~ +70°C |
| Storage Temperature | -40°C ~ +85°C |
| Package Dimensions | 5.5mm (Φ) x 35.0mm (L) |
Note1: All values specified are without connectors.
Note2: Higher performance specifications available upon request.
