| Parameter | ||
|---|---|---|
| Central Wavelength (λc) | 1310 nm & 1550 nm | |
| Bandwidth | ± 40 nm | |
| Attenuation Range | 1-30 dB | |
| Attenuation Tolerance | 1-9 dB | ± 0.5 dB |
| 10-14 dB | ± 1.0 dB | |
| 15-30 dB | ± 1.5 dB | |
| Return Loss | ≥ 50 dB (UPC) ≥ 60 dB (APC) |
|
| Maximum Power | 200 mW | |
| Attenuator Type | Pluggable (male to female) | |
| Operating Temperature | -40°C ~ +85°C | |
| Storage Temperature | -40°C ~ +85°C | |
Note 1: Higher performance specifications upon request.
Note 2: Default fiber type SMF-28e.
